Arc Guide (circular Guide): The Core Component of The 360 ° Precision Circulation Line

• turntable

The arc guide (arc guide) realizes the precision guidance of the circumference/arc trajectory, and is the "heart" of the circular production line, the rotating table, and the indexing mechanism.

Structure: Arc raceway (R50 - R2000mm) + slider/roller, can be spliced into a 0 ° - 360 ° round.

• type

Rolling type: high speed, high precision, low friction, suitable for electronic, medical light load circulation line.

Sliding type: heavy load, high rigidity, anti-vibration, suitable for machine tool turntable and heavy indexing disc.

Performance: Positioning accuracy ± 0.01mm, repeated positioning ± 0.003mm, load capacity up to 10 tons +.

Advantages: alternative to multi-axis linkage, compact structure, smooth movement, accurate positioning, space saving.

Typical applications: circular assembly line, robot seventh axis arc track, packaging/inspection rotary station.
