Product Overview
The product integrates core technologies such as precision transmission, precision guidance, and safety protection, and has the characteristics of fast expansion and contraction, accurate positioning, strong load bearing, and stable operation. It is widely used in various types of intelligent warehousing, logistics distribution centers, and industrial automation production lines. It is suitable for stackers, smart shuttles, and other equipment. It can customize the load, stroke, and installation size according to the actual needs of customers, providing efficient and reliable solutions for medium and heavy-duty and high-frequency cargo transfer, and helping enterprises improve the intelligence level of warehousing operations.
Core Advantage
Dual motor drive, double improvement in efficiency and stability: The dual motor independent drive structure is adopted, and the inner and outer section forks can achieve independent telescopic and synchronous linkage, avoiding the power shortage of single motor drive and the problem of telescopic card. The telescopic speed is increased by more than 30% compared with single motor forks, and the no-load telescopic speed can reach 50m/min. It can still maintain smooth operation under heavy load, greatly improving the efficiency of warehousing operations. At the same time, the dual motor redundancy design allows emergency operation when a single motor fails, reducing the risk of downtime and ensuring the continuity of operations.
Precise positioning with small operating errors: with high-precision encoders, limit switches, and dual-motor synchronization control technology, the positioning accuracy can reach ± 1-2mm, which can accurately realize the access and transfer of goods, avoid goods deviation and collision, and adapt to standard pallets and various special-shaped materials. It is especially suitable for warehousing scenarios in electronics, medicine, precision instruments, and other industries that require high positioning accuracy, enhancing the safety and accuracy of operations.
Strong load, wear-resistant and durable: The fork body is made of 42CrMo high-strength alloy steel. After overall quenching, high-frequency quenching, precision tempering and secondary forging treatment, the hardness can reach HRC58-62, and the resistance to deformation, wear and corrosion is excellent. The rated load can cover 500-2000kg, and it can withstand medium and heavy loads and high-frequency operations for a long time. The deflection of the fork body is controlled within a reasonable range, which greatly prolongs the service life of the product and reduces the frequency and cost of equipment maintenance.
Flexible customization and wide adaptability: Relying on professional R & D and processing teams, we can customize dual-motor telescopic forks with different strokes (1500mm-4000mm), different loads, and different installation sizes according to customer storage equipment parameters and operating conditions. It supports single-extension, double-extension, three-depth, and other structural customizations. It can be adapted to special working conditions such as high temperature, low temperature, dust-free, and humidity. It can be matched with suitable guide components and safety protection components to perfectly match various types of stackers and intelligent shuttles to meet the needs of diverse warehousing operations.
Safe and reliable, easy to operate: Equipped with a complete safety protection system, equipped with torque limiter, overload protection, emergency stop, anti-fork and other components, it can effectively prevent overload operation, excessive expansion, goods falling off and other safety hazards, and comprehensively ensure the safety of warehousing operations; the product adopts modular design, easy installation and disassembly, simple daily maintenance, and can be automatically controlled by PLC control system, adapting to intelligent warehousing system linkage, reducing manual intervention and improving the level of operation intelligence.
Applicable Scenario
It is widely used in automated three-dimensional warehouses, intelligent logistics distribution centers, industrial automated production lines, heavy-duty material warehousing and other fields, especially suitable for medium and heavy-duty, high-frequency, and high-precision operation scenarios, such as auto parts warehouses, new energy warehouses, pharmaceutical warehouses, electronic warehouses, large logistics transit centers, etc. It can be used as the core executive component of stackers and intelligent shuttles to undertake the tasks of cargo access, transfer, and transshipment. It is suitable for standard pallets such as 1200mm × 1000mm and 1200mm × 1200mm, as well as various heavy and precision materials, to help enterprises achieve efficient, intelligent, and safe operation of warehousing operations.
Product Features
Drive mode: dual motor independent drive, inner and outer section fork body can be independently telescopic, synchronous linkage, strong power, stable operation;
Material process: 42CrMo high-strength alloy steel, quenched, forged, precision grinding treatment, wear resistance, corrosion resistance, anti-deformation;
Accuracy parameters: positioning accuracy ± 1-2mm, no-load telescopic speed ≤ 50m/min, rated load 500-2000kg;
Structural specifications: support single extension, double extension, three deep position structure, stroke 1500mm-4000mm, support full specification non-standard customization;
Safety configuration: equipped with torque limiter, overload protection, limit switch, anti-fork and other components, comprehensive safety protection;
Adaptation scenarios: It can be matched with stackers and intelligent shuttles, suitable for various working conditions such as room temperature, high and low temperature, dust-free, etc., and suitable for medium and heavy load and high frequency operations.
